Automatic Bearing Inner And Outer Diameter Inspection Machine

SYSTEM DESCRIPTION:

Process flow:

Conveyor belt loading → inner and outer ring transportation → inner and outer diameter inspection → inner and outer height inspection → rework removal → scrap removal → qualified product discharge

Products Description

Message

Accuracy indicators:

Single point repeated measurement of inner diameter 10 times ≤ 1 μM

Single point repeated measurement of outer diameter 10 times ≤ 1 μM

10 repeated measurements of height at a single point ≤ 1 μM



Featured features:

Customizable series of error prevention functions

Overall appearance design such as installing a hood

Customized operation direction for the entire machine, suitable for various whole line schemes

Device model JR-NW01 JR-NW02
Scope of application Bearing outer diameter 22-50mm Bearing outer diameter 50-100mm
Work Efficiency ≤ 3 seconds ≤ 5 seconds
Working Voltage 220V/50Hz/1.5A
Working air pressure ≥0.4MPa
Overall dimensions L800×W600×H1800mm L1100×W700×H1800mm
