The bearing inner and outer ring feeder adopts an efficient automation design. Through a precise feeding system, it can quickly and accurately feed the inner and outer rings of bearings into the produ...
READ MOREInner/outer ring feeding machine→Inner ring groove measuring machine→Discharge machine→Inner and outer ring sorting machine→Inner and outer ring sealing machine→Cleaning machine→Suction drying machine→Vibration detection machine→Clearance detection machine→Grease capping machine→Reverse grease capping machine→Torque detection and gear ring pressing machine→Bolt pressing and outer flange jumping detection machine→Laser marking machine→Oiling machine→Material handling machine
OR OD |
Φ80-150mm |
W |
50-80mm |
IR BD |
Φ20-40mm |
CT |
≤18s |
Accuracy |
Measuring the clearance after 20 repeated cycles, repeating accuracy≤3µm |
MeasuringRacewaysortingafter20repeatedcycles,repeatingaccuracy≤1.5µm |
|
Runout measurement after 20 repeated cycles error:±2.5µm |
